Portable P6 High Brightness Led Display Hire Lightweight Customized Logo

Product Categories

Shenzhen LED World Co.,Ltd

Contact Now

Name: Portable P6 High Brightness Led Display Hire Lightweight Customized Logo
Brand: Shenzhen LED World
Price: 1 USD

Brand Name : Shenzhen LED World

Model Number : LW-RO 6

Certification : CE,RoHS,FCC,CCC

Place of Origin : China

MOQ : 1 square meter

Price : negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 2000 sqm/month

Delivery Time : 12~20 working days after deposit received

Packaging Details : Carton/Plywood case/Flight case etc.

Grey scale : RGB Each 256, can display 16.7M colors)

Power switch : Automatic Switch

Operating Voltage : AC220V±10%

Electric current : ≤20mA(single LED)

Operating system : WIN98/2000/NT/XP

Cabinet resolution : 96*96dots

Interface : HUB75

Product Model : P6 surface mounted Module

Contact Now

Portable P6 led display rental outdoor high-precision screen panel with die-casting

Product Description:

Constant current IC driver;
Can load more cabinets in 1 flight case--save cost;
Perfect for outdoor usage;
14 bit color,16384 gray scale,showing very clear and vivid video and images;
Easy installation design, allows for quick and convenient installation;
Made with SMD2727 led lamps, high contrast and wide view angle up to 140/140(H/V);
Horizontal viewing angle is 160 degree;
Cabinets are made of die-casting aluminium,can be spliced with no crack；
Lightweight
Aluminum cabinet greatly saving fright cost and conveniently installing;
Die-casting aluminium cabinet, light, strong and precise, tolerance within 0.2mm.

Why choose us:

Parameter:

The specifications of modules
Items			Parameter
Product Model			P6 surface mounted Module
Module size			192mm*192mm
Pixel pitch			6mm
Pixel density			27777dots/m2
Pixel configuration			SMD 3in1
Module resolution			32dots(W)*32dots(H)
Module maximum power consumption			20W
Module Thickness			2CM
Module Weight			0.55kg
Driving method			Constant Current Driving
Scanning method			1/8 scan
Interface			HUB75
Brightness			≥5500cd/m2
The specifications of cabinets
Cabinet size			576mm*576mm
Module quantity			9pcs
Power supply			5V/40A 5V/60A
Cabinet resolution			96*96dots
Optimal viewing distance			5M~50M
Optimal viewing angle			160°(W) 120°(H)
RHWorking temperature			(Work :-20°C~+60°C)
System operating humility			10%-95%
The specifications of power supplier
Operating Voltage			AC220V±10%
Average power consumption			400W/H
Maximum power consumption			≤400W/m2
Electric current			≤20mA(single LED)
The specifications of control card
Control Panels			Pentium4 or above P4 or above
Operating system			WIN98/2000/NT/XP
Control model			Synchronization with PC
The specifications of the main technical parameters
Driving device			Constant Current Driving
Refresh rate			≥1920HZ
Grey scale			RGB Each 256, can display 16.7M colors)
MTBF			≥9000hours
Power switch			Automatic Switch
Display Mode			800600/1024768/1280*900
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

FQA:

What's the pixel pitch for Outdoor LED Display Screen?
Outdoor(p3.91mm/p4.81/p5mm/P6mm/p6.25/p6.67/ P8mm/P10mm/p16mm/p20mm) led display screen;
What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you;
Are you manufacturer of led display.If yes, in which city?
Yes, Our factory with 9000 square meters. And we're in SHENZHEN city, GUANGDONG Province;
How about your production ability?
We have 10 production lines with all series of automatic production machines.
Monthly production ability: 200,000pcs of led modules and 4,000sqm of assembled led displays;
How long can I get the goods?
Our produce time is about 10-25 working days.When you confirmed the order, we can start production
after receiving your deposit(30% TT in advance). we will update the production details in time.we will
notice you that we can delivery the goods to you after we get full payment;
How about your quality control?
Quality control starts from strict raw material purchase.
Each product will run through aging test for 72 hours.

Product detail:

Portable P6 High Brightness Led Display Hire Lightweight Customized Logo
