Mobile Led Screen Rental 1R1G1B 1/8 Scan

Shenzhen LED World Co.,Ltd
Contact Now

Mobile Led Screen Rental 1R1G1B 1/8 Scan

Brand Name : Shenzhen LED World

Model Number : LW-FO 6

Certification : RoHS,FCC,CCC,CE

Place of Origin : China

MOQ : 1 pcs

Price : negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 5000 pcs/month

Delivery Time : 10~18 working days after deposit received

Packaging Details : Plywood case

Drive type : Constant drive

Power Supply : G-energy Ultra thin

LED Lamp : SMD 3535

Cabinet Size : 576mm x 576 mm

Port type : HUB75-A

Scan mode : 1/8

Module size : 192x192mm

Contact Now

Truck Mobile LED Display outdoor full color screen board panel P6 1R1G1B 1/8 scan.

Features:

  • the aviation plug connector choose professional, quality safety guarantee;
  • High brightness and support brightness automatically adjustment;
  • Good quality of led chips;
  • Compatible with multiple signal source input, such as AV, S-video, DVI, VGA, YPbPr, HDMI, SDI, DP etc.5.High wear-resistant glass mask, which make its on the ground can be trampled directly and to guarantee the screen body are not damaged;
  • Pitch size 5mm;
  • High brightness up to 6000nits, close view distance,good performance;
  • Good waterproof IP65, suit to any weather,anti-corrossion,long life span;
  • Working temperatue: -20degree-+80degree;
  • MTBF: More than 10, 000hours;
  • HQ-image.Good consistency / No particle and mosaic phenomenon;

Parameter:

Quick Details Place of Origin: Shenzhen,Guangdong, China (Mainland)
Brand Name: Shenzhen LED World
LED Lamp: SMD 3535
Tube Chip Color: Full Color
Display Function: Video
LED Lamp Brand : Epistar
Power Supply: G-energy Ultra thin
IC Driver: MBI 5141
Driving Method 1/8 scan
Pixel Density 27777 dots/ SQ.M
Viewing angle: 140H,120V
Cabinet Size: 576mm x 576 mm
certificates: CE,RoHs,CCC,ISO9001
Module Parameters Model Number LW-FO 6
Module size 192mm *192mm
Pixel pitch 6mm
Pixel configuration 1R1G1B
Pixel resolution 32dots(W)* 32 dots(H)
Max Power 60W
Drive type Constant drive
Scan mode 1/8
Port type HUB75-A
Brightness of white balance ≥6000 Nits/SQ.M
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Applications:

Wide applied in banks, chain shop,entertainment TV,station weiting area, museum,convention center,aiming at the exhibition,railway stations and so on .

Our service:

  • We offered technical advice to you before buying our products;
  • Distributer ship are offered for your unique design and some our current models;
  • The size can be change as you give, your customized lightings we can help you to design and put into product;
  • Monthly production capacity: 3000 Sq. M;
  • Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions;
  • All the led display are inspected before shipment.IP65 is better than other suppliers;

Project case:

Mobile Led Screen Rental 1R1G1B 1/8 Scan

Mobile Led Screen Rental 1R1G1B 1/8 Scan

Mobile Led Screen Rental 1R1G1B 1/8 Scan
